Concrete Drilling Range(mm) | Rated Voltage(v) | Rated Frequency(Hz) |
Rated Input Power(w) |
No-load Speed(rpm) | Cable length(m) | Borehole Depth(mm) |
Net/Gross Weight(Kgs) |
Packing Size(cm) |
|---|---|---|---|---|---|---|---|---|---|
| DK-406/2 | ~16”(~406) | 110/220~ | 50-60 | 5580 | 280/440 | 3.5 | 600 | 32/35 | 104*38*24 |
| DK-406/2E | ~16”(~406) | 110/220~ | 50-60 | 5580 | 100-280/440 | 3.5 | 600 | 32/35 | 104*38*24 |
| DK-406/3 | ~16”(~406) | 110/220~ | 50-60 | 5580 | 280/410/550 | 3.5 | 600 | 32/35 | 104*38*24 |
| DK-406/3E | ~16”(~406) | 110/220~ | 50-60 | 5580 | 100-280/410/550 | 3.5 | 600 | 32/35 | 104*38*24 |
| DK-450/2 | ~18”(~450) | 110/220~ | 50-60 | 5680 | 240/380 | 3.5 | 600 | 33/36 | 104*38*24 |
| DK-450/2E | ~18”(~450) | 110/220~ | 50-60 | 5680 | 100-240/380 | 3.5 | 600 | 33/36 | 104*38*24 |
| DK-450/3 | ~18”(~450) | 110/220~ | 50-60 | 5680 | 240/360/480 | 3.5 | 600 | 33/36 | 104*38*24 |
| DK-450/3E | ~18”(~450) | 110/220~ | 50-60 | 5680 | 100-240/360/480 | 3.5 | 600 | 33/36 | 104*38*24 |
| DK-506/2 | ~20”(~506) | 110/220~ | 50-60 | 5780 | 220/360 | 3.5 | 600 | 34/37 | 104*38*24 |
| DK-506/2E | ~20”(~506) | 110/220~ | 50-60 | 5780 | 100-220/360 | 3.5 | 600 | 34/37 | 104*38*24 |
| DK-506/3 | ~20”(~506) | 110/220~ | 50-60 | 5780 | 220/350/460 | 3.5 | 600 | 34/37 | 104*38*24 |
| DK-506/3E | ~20”(~506) | 110/220~ | 50-60 | 5780 | 100-220/350/460 | 3.5 | 600 | 34/37 | 104*38*24 |
